Electric Forklift CPDB-20
- Commodity name： Electric Forklift CPDB-20
Phone:
+86 199 3194 8292
- Product Description
- 参数
-
Electric Forklift
Product Introduction:
The Electric Forklift CPDL-20 exemplifies quality counterbalanced electric stacker engineering, featuring a impressive 4,409 lbs. (2,000 kg) capacity and a maximum lift height of 118.1 inches (300 cm). Powered by lithium-ion or lead-acid batteries, it offers up to 5-7 hours of continuous operation with quick charging capabilities (2-4 hours). As a premier supplier of advanced counterbalanced electric stacker from China manufacturers, we ensure optimal maneuverability with a tight 87.8-inch (223 cm) turning radius and solid pneumatic tires for stability across various floor conditions.
Designed for operator comfort and safety, the CPDB-20 includes essential features like an emergency stop button, anti-rollback system, and operator restraint. Its customizable fork length (standard 42.13 inches/107 cm) and lift height adapt to diverse loading scenarios, while the compact dimensions (94.49” x 45.28” x 82.68”) enable efficient operation in confined spaces. For businesses seeking a quality counterbalanced electric stacker that combines power, precision, and durability, our solution from China's top manufacturers represents the perfect balance of performance and value.
Key Advantages:
Zero-emission electric operation for indoor/outdoor use
Extended battery life with quick-charge capability
Superior load stability with counterbalanced design
Ergonomic controls for reduced operator fatigue
Adaptable configuration for various material handling needs
Zero-Emission Powertrain
Equipped with a state-of-the-art lithium-ion battery, our forklift eliminates emissions and reduces your carbon footprint.
Advanced Operator Interface
The intuitive touchscreen interface offers real-time diagnostics, enhancing operator efficiency and safety.
Ergonomic Design for Operator Comfort
The ergonomic cab design ensures operator comfort during extended shifts.
High-Capacity Lifting and Precision Control
Equipped with a sturdy lifting device, the CPDB Series Electric Forklift combines strength with precision control.
Product Specifications
Model CPDB-20 Capacity 4,409 lbs. (2,000 kg) Power Source Lithium-ion Battery / Lead-acid Battery Battery Life Up to 5-7 hours per full charge Charging Time 2-4 hours (quick charge option available) Maximum Lift Height 118.1 inches (300 cm) (customizable) Fork Length 42.13 inches (107 cm) standard (customizable) Travel Speed Up to 7.46 mph (12 kph) Turning Radius 87.8 inches (223 cm) Tight, maneuverable radius for narrow aisles Tire Type Solid pneumatic for stability and durability Dimensions (LxWxH) 94.49” x 45.28” x 82.68” (240 cm x 115 cm x 210 cm)
Weight Approximately 6,614 lbs. (3,000 kg) Safety Features Emergency stop button, anti-rollback system, operator restraint, and more -
-
CHARACTERISTICS
- Model Code CPDB-20
- Capacity 2000 kg
- Operator Type Seat type
- Load Center 500 mm
- Free Lifting Height 115 mm
- Lowered Fork Height 2100 mm
- Max. Lifting Height 3000 mm
- Weight 3000 kg
- Overall Length 3490 mm
- Overall Width 1150 mm
- Fork Dimensions 40*122*1070 mm
- Ground Clearance 110 mm
- Turning Radius 2230 mm
- Travel Speed 12 km/h
- Lift Speed 0.24 m/s
- Gradeability 15 %
- Drive Motor 7.5 kw
- Lift Motor 7 kw
- Battery Voltage 60V / 280 Ah
- Overall Height Fork Lowered
-
